AOC CU34G3S User Manual

24
Specification
General Specification
Panel
Model name CU34G3S
Driving system TFT Color LCD
Viewable Image Size 86.36 cm diagonal
Pixel pitch
0.23175mm(H) x 0.23175mm(V)
Video HDMI lnterface & DP Interface
Display Color 16.7M Colors
Others
Horizontal scan range
30-160KHZ(HDMI)
30-250KHZ(DP)
Horizontal scan Size(Maximum) 797.22mm
Vertical scan range
48-120HZ(HDMI)
48-165HZ(DP)
Vertical Scan Size(Maximum)
333.72mm
Optimal preset resolution 3440x1440@60Hz
Max resolution
3440x1440@100Hz(HDMI)
3440x1440@165Hz(DP)
Plug & Play VESA DDC2B/CI
Input Connector HDMI/DP
Power Source 100-240V~, 50/60Hz,1.5A
Power
Consumption
Typical (default
brightness and contrast)
57W
Max. (brightness = 100,
contrast =100)
≤110W
Standby mode ≤0.5W
Physical
Characteristics
Connector Type HDMI/DP/USB/Earphone out
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )

AOC CU34G3S Specifications

General

Panel type	VA
Pixel pitch	0.23175 x 0.23175 mm
Backlight type	W-LED
Display diagonal	34 \
Surface hardness	3H
Anti-glare screen	Yes
Adobe RGB coverage	96 %
Display technology	LED
Native aspect ratio	21:9
NTSC coverage (typical)	98 %
Screen curvature rating	1000R
sRGB coverage (typical)	119 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	86.36 cm
Display brightness (typical)	300 cd/m²
AMD FreeSync type	FreeSync Premium
AMD FreeSync refresh rate range	48 - 165 Hz
Exterior finish type	Textured
Feet color	Black
Certification	WEEE, CB, Microsoft WHQL
Product color	Black, Red
Front bezel color	Black/Red
Market positioning	Gaming
RMS rated power	10 W
Number of speakers	2
Tilt angle range	-5 - 21.5 °
Height adjustment	130 mm
Cable lock slot type	Kensington
Number of OSD languages	19
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone outputs	1
DisplayPort version	1.4
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	57 W
Package width	900 mm
Package height	525 mm
Package weight	12100 g
Cables included	AC, DisplayPort, HDMI
HDMI cable length	1.8 m
Sustainability certificates	WEEE
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	339.5 mm
Width (with stand)	794.8 mm
Height (with stand)	532 mm
Weight (with stand)	8250 g
Depth (without stand)	133.4 mm
Height (without stand)	365.8 mm
