AOC e2050Swd Service Manual

46
CN402
033G3802 6B Y L
WAFER
CN701
033G3802 9B Y L
CONN 2.0 9P
CN408
033G801930F CH L
FFC CONN 1.0mm 30P R/A 34mm 6mm
CN101
088G 35315FVCL
D-SUB CONN V/T 15P BLUE H=10.4
CN102
088G 35424FVXH
DVI CONN V/T 24P WHITE
X401
093G 2251BCEC
CRYSTAL S-F-12.000M-30-3030-2085-25
709G4502 HM001
COMSUPTIVE ASS'Y
H40G 45762429A
LABEL
LED001
081G 12 1F GH
LED GREEN/YELLOW GHZYG603D2-5B
CN001
095G820H 6TE10
HARNESS 6P(SANW)-6P(2008) 120mm
709G4747 HM001
COMSUPTIVE ASS'Y
GND1
009G6005 1
GND TERMINAL
U902
056G 139 9
IC EL817M(X) photocoupler DIP-4
NR901
061G 5810X
NTCR 8R 20% 4W 8D2-14 MCS
C908
063G107K474 6S
0.47UF +-10%
C809
067G 415330 9K
EC 33UF 20% 100V ED 8*12
C907
067G 42Z68015K
EC 68UF 20% 450V 12.5*50 2000 hr
L901
073G 174 65 H2
LINE FILTER 30mH MIN
L906
073G 253191 H
IND CHOKE 1.1uH DADON
L801
073G 253214 DN
CHOKE COIL 47UH 10% LZ.CC013.G01 2.5A
T901
080GL22T 3 S3
X'FMR 490UH 7% 4UH BCK-ER28-22210
CN901
087G 501 48 DL
AC SOCKET 3PIN + 3 Hole
BD901
093G 50460514
BRIDGE KBP306G-05 3A 800V KBP
D901
093G 60335
DIODE SR515 5A/150V DO-201AD
D909
093G 60519
DIODE SR560-MK23 5A/60V DO-27 SECOS
D905
093G 60519
DIODE SR560-MK23 5A/60V DO-27 SECOS
CN902
095G 825 9D905
HARNESS 9P(SCN) - 9P 80mm FQE100911I
CN804
311GW200A06ABX
WAFER 2.0mm 6P
D801A
393G0060A0400T
SCHOTTKY SR310-29 X0 3A 100V High£½6mm
705GHA57006
Q901 ASS"Y
709G4744 HM001
CONSUMPTIVE ASS'Y
H40G 45762429A
LABEL
Q55G 100625
TIN STICK_LOW ARGENTUM
C702
067G 3051013PB
EC 105C 100uF M 16V 5*11mm JH CD263
C433
067G 3051013PB
EC 105C 100uF M 16V 5*11mm JH CD263
C716
067G 3051013PB
EC 105C 100uF M 16V 5*11mm JH CD263
C705
067G 3051013PB
EC 105C 100uF M 16V 5*11mm JH CD263
R002
061G0603000 FF
RST CHIPR MAX0R01 1/10W FENGHUA
R004
061G06031001FF
RST CHIPR 1 KOHM +-1% 1/10W FENGHUA
R003
061G06032001FF
RST CHIP 2KOHM 1% 1/10W FENGHUA
R001
061G06032001FF
RST CHIP 2KOHM 1% 1/10W FENGHUA
Q901
057G 667941
MOSFET P0765ATF 7 650 TO-220F
HS1
090G6064 1
HEAT SINK
0M1G 930 8120
SCREW 3x8
055G 23524
WELDING FLUX WITHOUT PB
Q51G 6 4509
GLUE_RTV
Q55G 100625
TIN STICK_LOW ARGENTUM
U901
056G 379529
AC/DC CONVERTER IC LD7576AGR SOP-7
U801
056G 700 11
LED DRIVER OZ9998BGN-A1-0-TR SOP-16
Q801
057G 763 92
FET P8008HV 4A/80V SOP-8
RJ801
061G0805000 JF
RST CHIPR 0 OHM +-5% 1/8W FENGHUA
R804
061G0805100 JF
RST CHIPR 10 OHM +-5% 1/8W FENGHUA

AOC e2050Swd Specifications

General

Color	glossy black, black
Screen Type	led
Webcam	no
OS Compatibility	windows
Screen Size	20 inches
Aspect Ratio	16:9
Resolution	1600 x 900
Native Resolution	1600 x 900
Refresh Rate	60hz
Horizontal Viewing Angle	90 degrees
Vertical Viewing Angle	50 degrees
Response Time	5 milliseconds
Brightness	200 candela per square meter
Contrast Ratio	20, 000, 000:1
Horizontal Scan Rate	83 kilohertz
VGA Ports	1
DVI	1
Power Saving Mode	0.5 watts
Power Consumption	17 watts
Width with Stand	18.8 inches
Net Weight without Stand	6.2 pounds
