6
3. Operating Instructions
3.1 General Instructions
Press the power button to turn the monitor on or off. The other control knobs are located at front panel of the monitor
(See Figure ). By changing these settings, the picture can be adjusted to your personal preferences.
* The power cord should be connected.
* Press the power button to turn on the monitor. The power indicator will light up.
3.2 Control Buttons and Connections
Power
Press the Power button to turn on/off the monitor.
Eco (DCR)/ -
Press the Eco key continuously to select the Eco mode of brightness and DCR on when there is no OSD. ( Eco mode
hot key may not be available in all models).
Volume
When there is no OSD, Press Volume button to active volume djustment bar, Press - or + to adjust volume(Only for
the models with speakers)
4 : 3 or wide/+
When there is no OSD, Press + continuously to change 4:3 or wide image ratio. (If the product screen size is 4:3 or
input signal resolution is wide format, the hot key is disable to adjust. )
Auto / Exit
When there is no OSD, press Auto / Exit button continuously to do auto configure. (For the models with one input)
When there is no OSD, press Auto / Exit button continuously about 3 second to do auto configure. (Only for the
models with dual or more inputs)
Source hot key
When the OSD is closed, press Source button will be Source hot key function. Press Source button continuously to
select the input source showed in the message bar , press Menu/Enter button to change to the source selected. (Only
for the models with dual or more inputs).
To Next Page
