AOC e2050Swd Service Manual

5
2.LCD Monitor Description
The LCD monitor will contain a main board, a power board and a key board which house the flat panel control logic,
brightness control logic and DDC.
The power part will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each
voltage.
Monitor Block Diagram
AC-IN
100V-240V
Power Board
Flat Panel and
LED backlight
Main Board
RS232 Connector
For white balance
adjustment in factory
mode
LED Drive.
Video signal, DDC
HOST Computer
Key Board

AOC e2050Swd Specifications

General

Color	glossy black, black
Screen Type	led
Webcam	no
OS Compatibility	windows
Screen Size	20 inches
Aspect Ratio	16:9
Resolution	1600 x 900
Native Resolution	1600 x 900
Refresh Rate	60hz
Horizontal Viewing Angle	90 degrees
Vertical Viewing Angle	50 degrees
Response Time	5 milliseconds
Brightness	200 candela per square meter
Contrast Ratio	20, 000, 000:1
Horizontal Scan Rate	83 kilohertz
VGA Ports	1
DVI	1
Power Saving Mode	0.5 watts
Power Consumption	17 watts
Width with Stand	18.8 inches
Net Weight without Stand	6.2 pounds
