AOC E2236VW - 5 Block Diagram; Main Board

21.5" LCD Color Monitor AOC e2236Vw
32
5. Block Diagram
5.1 Main Board
715G3329 1 2
FLASH MEMORY
MX25L2026MI
(U402)
Scalar TSUMU58PWHL-LF-1
(Include :MCU,ADC,OSD etc)
(U401)
LCD Interface
(CN301)
D-Sub
Connector
(CN101)
Crystal 14.31818MHz
(X401)
DVI
Connector
(CN102)
Key Control
Interface
(CN402)
