21.5" LCD Color Monitor AOC e2236Vw
4
1. Monitor Specifications
LCD Panel
Model name e2236Vw
Driving system TFT Color LCD
Viewable Image Size 547mm diagonal
Pixel pitch 0.248mm(H) x 0.248mm(V)
Video R, G, B Analog lnterface & Digital Interface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 148.5 MHz
Resolution
Horizontal scan range 30 kHz - 80 kHz
Horizontal scan
Size(Maximum)
476.64mm
Vertical scan range 55 Hz - 75 Hz
Vertical scan Size(Maximum) 268.11mm
Optimal preset resolution 1920 x 1080 (60 Hz)
Highest preset resolution 1920 x 1080 (60 Hz)
Plug & Play VESA DDC2B/CI
Input Connector D-Sub 15pin & DVI-D
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source 100-240V, 50/60Hz
Power Consumption
Typical < 42 W
Standby < 1 W
USB Downstream port (A type ) To USB device, loading < 100mA
off timer 0~24hours Select timing to turn off the monitor.
Physical
Characteristics
Connector Type 15-pin Mini D-Sub & DVI-D
Signal Cable Type Detachable
Dimensions & Weight:
Height (with base) 396.6 mm
Width 531.3mm
Depth 206mm
Weight (monitor only) 4.35 kg
Weight (with packaging) 5.8 kg
Environmental
Temperature:
Operating 0° to 40°
Non-Operating -20°to 60°
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 80% (non-condensing)
Altitude:
Operating 0~ 3000m (0~ 10000 ft )
Non-Operating 0~ 5000m (0~ 15000 ft )
