5.2 Power Board
715G3980P04000003M
12V/3A
EMI filter
Start Resistor
(R906,R934)
PWM Control
LD7750GS
(IC901)
Bridge
Rectifier
and Filter
Rectifier
diodes
Transformer
(T901)
Regulator
(IC903)
Photo coupler
(IC902)
Power Switch
(Q901)
