AOC e2262Vwh Service Manual

5
Panel
Model name
E2462VW/E2462VWH
Driving system
TFT Color LCD
Viewable Image Size
59.8 cm diagonal
Pixel pitch
0.2715mm(H) x 0.2715mm(V)
Video (E2462VW)
R, G, B Analog lnterface & Digital Interface
Video (E2462VWH)
R, G, B Analog lnterface & HDMI lnterface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
148.5 MHz
Resolution
Horizontal scan range
30 kHz - 83 kHz
Horizontal scan Size(Maximum)
521.28mm
Vertical scan range
50 Hz - 76 Hz
Vertical scan Size(Maximum)
293.22mm
Optimal preset resolution
1920 x 1080@60Hz
Plug & Play
VESA DDC2B/CI
Input Connector ( E2462VW)
VGA/DVI
Input Connector (E2462VWH)
VGA/HDMI
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source
12Vdc,3.0A
Power Consumption
Active 24W (typical)
Standby < 0.5 W
Off timer
0-24 hrs
Physical
Characteristics
Connector Type (E2462VW)
VGA/DVI
Connector Type (E2462VWH)
VGA/HDMI
Signal Cable Type
Detachable
Environmental
Temperature:
Operating
0° to 40°
Non-Operating
-25°to 55°
Humidity:
Operating
10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)
Altitude:
Operating
0~ 3658m (0~ 12000 ft )
Non-Operating
0~ 12192m (0~ 40000 ft )
