22’’ LCD TV AOC L22W631
14
3.3 AV/S-Video/Component Video Inputs
AV
(Composite Video)
Video system
PAL / NTSC-M
Amplitude
1.0Vpp (including sync)
Impedance
75 ohm terminated
S-Video
Video system
PAL/ NTSC-M
Y signal amplitude
1.0Vpp (including sync)
C signal amplitude
0.286Vpp
Impedance
75 ohm terminated
Component Video
Video System
DTV
480i, 480p, 576i,576p,720p, 1080i
Y signal amplitude
1.0Vpp (including sync)
Pr/ Pb signal amplitude
0.7Vpp
Impedance
75 ohm terminated
3.4 HDMI Inputs
HDMI
( EIA/CEA-861B )
Output Formats
H/V Frequency
HZ
Resolution
Component
1.
480 I (SDTV)
15.734K / 60
720 - 240
2.
480 P(SDTV)
31.469K / 60
720 - 480
3.
576 I(SDTV)
15.625K / 50
720 - 288
4.
576 P(SDTV)
31.250K / 50
720 - 576
5.
1080I /60 (HDTV)
33.750K / 60
1920 - 1080
6.
1080I /50 (HDTV)
28.125K / 50
1920 - 1080
7.
720P /60 (HDTV)
45.00 K / 60
1280 - 720
8.
720P /50 (HDTV)
37.50 K / 50
1280 - 720
