Wall Mounting

Preparing to Install An Optional Wall Mounting Arm.

This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this procedure.

Follow these steps:

1. Remove the base.

2. Follow the manufacturer’s instructions to assemble the wall mounting arm.

3. Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the holes in the back of the

monitor.

4. Insert the 4 screws into the holes and tighten.

5. Reconnect the cables. Refer to the user’s manual that came with the optional wall mounting arm for instructions on

attaching it to the wall.

Noted:

VESA mounting screw holes are not available for all models, please check with the dealer or ofcial

department of AOC.

* Display design may differ from those illustrated.

WARNING:

1. To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward by more than

-5 degrees.

2. Do not press the screen while adjusting the angle of the monitor. Grasp only the bezel.

Questions and Answers:

Need help?

Do you have a question about the AOC Q27P3CW and is the answer not in the manual?

AOC Q27P3CW Specifications

General

Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Pixel density	109 ppi
Backlight type	W-LED
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
Supported video modes	1080p, 1440p, 2160p
NTSC coverage (typical)	102 %
sRGB coverage (typical)	117 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Display brightness (typical)	350 cd/m²
Compatibility	VESA-P2
NVIDIA G-SYNC	-
Certification	Windows Hello EPA, TCO, EPEA
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Gaming
Megapixel	5 MP
RMS rated power	5 W
Number of speakers	2
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, ENG, ESP, FIN, FRE, ITA, JPN, POL, SWE
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	26 W
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
USB Power Delivery up to	65 W
USB Type-A downstream ports quantity	4
Cables included	AC, DisplayPort, HDMI, USB Type-C
DisplayPort cable length	1.8 m
Doesn't contain	PVC/BFR
Sustainability certificates	TCO
Exterior finish type	Textured
Recyclable packaging material	100 %
Mean time between failures (MTBF)	70000 h
Package depth	162 mm
Package width	820 mm
Package height	481 mm
Package weight	10080 g
