AOC Q27P3CW User Manual

28
Specification
General Specification
Panel
Model Name Q27P3CW
Driving System TFT Color LCD
Viewable Image Size 68.5 cm Diagonal (27’’ Wide Screen)
Pixel Pitch
0.2331mm(H) x 0.2331mm(V)
Others
Horizontal Scan Range 30k-114kHz
Horizontal scan Size(Maximum) 596.736 mm
Vertical Scan Range 48-75Hz
Vertical Scan Size(Maximum) 335.664mm
Max resolution
2560x1440@75Hz
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz, 1.5A
Power Consumption
Typical(Default Brightness And Contrast)
26W
Max. (Brightness = 100, Contrast =100) ≤152W
Standby Mode
≤
0.5W
USB C
USB-C Double-sided Connectable Plug
Ultra-highSpeed Data And Video Transmission
DP Built-in DP Alt Mode
Power Supply USB PD Version 3.0
Maximum Power Supply
Up to 65W (5V/3A,7V/3A,9V/3A,10V/3A, 12V/3A,15V/3A,
20V/3.25A)
Physical
Characteristics
Input Connector
HDMIx2/DP IN/DP OUT/Earphone/RJ45 Input/USB C/
USB3.2 Gen1x4(Includes 1 Fast Charger)
RJ45 Ethernet LAN (10M/100M/1000M)
Signal Cable Type Detachable
Environmental
Temperature
Operating 0°C ~ 40°C
Non-Operating -25°C ~ 55°C
Humidity
Operating 10% ~ 85% (Non-Condensing)
Non-Operating 5% ~ 93% (Non-Condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )

AOC Q27P3CW Specifications

General

Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Pixel density	109 ppi
Backlight type	W-LED
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
Supported video modes	1080p, 1440p, 2160p
NTSC coverage (typical)	102 %
sRGB coverage (typical)	117 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Display brightness (typical)	350 cd/m²
Compatibility	VESA-P2
NVIDIA G-SYNC	-
Certification	Windows Hello EPA, TCO, EPEA
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Gaming
Megapixel	5 MP
RMS rated power	5 W
Number of speakers	2
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, ENG, ESP, FIN, FRE, ITA, JPN, POL, SWE
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	26 W
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
USB Power Delivery up to	65 W
USB Type-A downstream ports quantity	4
Cables included	AC, DisplayPort, HDMI, USB Type-C
DisplayPort cable length	1.8 m
Doesn't contain	PVC/BFR
Sustainability certificates	TCO
Exterior finish type	Textured
Recyclable packaging material	100 %
Mean time between failures (MTBF)	70000 h
Package depth	162 mm
Package width	820 mm
Package height	481 mm
Package weight	10080 g

Weight and Dimensions

Depth (with stand)	200.1 mm
Width (with stand)	613.8 mm
Weight (with stand)	6910 g
Depth (without stand)	52.8 mm
