13
APPENDIX
SPECIFICATIONS
CRT Size
43.2cm(17"), 90º deflection, 29mm
neck,
CRT Viewable Image
Size
40.6cm (16"), diagonal
Type 0.28mm dot pitch.
Video 0.7Vpp, R,G,B Analog
Input Separate Sync. TTL Level
H./V.- Sync. Positive / Negative
Scanning H-Frequency 30kHz - 70kHz
Frequency V-Frequency 50Hz-160Hz
Max. Resolution 1280 x 1024
Video Bandwidth 100MHz
Factory Preset mode : 9
User
Programmable
mode : 20
Power Source Universal AC 100 - 240V,
50Hz / 60Hz
Operating 0ºC to 40ºC ambient
Humidity
10%to 85%relative, non-condensing
Dimensions
7Vlr/7Vlr+: Monitor & Base 410(W) × 411(H) × 430(D)mm
7VlrA/7VlrA+: Monitor & Base 410(W) × 448(H) × 430(D)mm
Weight
7Vlr/7Vlr+: Unit (net) 16.0kgs ( Net )
7VlrA/7VlrA+: Unit (net) 16.8kgs ( Net )
Signal Cable: Attached Mini D-sub 15 Male
410
411
430
(in mm)
7Vlr/7Vlr+
