20
5. Block Diagram
5.1 Main board
Key Control
interface
(CN408)
LCD Interface
(CN405)
Scalar IC HX6820-A080LAG
(Include MCU, ADC, OSD)
(U401)
EEPROM
MX25L2026DM1I-12G
(U402)
Crystal
24.576MHZ
(X401)
EEROM
M24C02-RMN6TP
(U101)
D-SUB
Connector
(CN101)
EDID_WP
VGA-SCL
VGA-SDA
H sync
V sync
RGB
