1. Monitor Specification
LCD Panel
Driving system
18.5”W LCD Monitor with LED Backlight
Size 47.0cm
Pixel pitch 0.3mm( H ) x 0.3mm( V )
Input
Video R,G,B Analog Interface
H-Frequency 30KHz – 83KHz
V-Frequency 55-75Hz
Display Colors 16.7M Colors
Dot Clock 85.5MHz
Max. Resolution 1366 x 768 @60Hz
Plug & Play VESA DDC1/2B
TM
Input Connector D-Sub 15pin
Input Video Signal
Analog:0.7Vp-p(standard),
75 OHM, Positive
Maximum Screen Size
Horizontal : 409.8mm
Vertical : 230.4mm
Power Source 100-240V,50/60Hz,1.5A
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp.: -25° to 55°C
Operating Humidity: 10% to 85%
Weight (N. W.) 2.7 kg Unit (net)
Dimension 440mm x 341mm x 180mm
Power Consumption ( Maximum ) 20 Watts
External Controls:
Switch
Auto Adjust button / Exit
-/ ECO
+ / Image Ratio
Menu / Enter
Power Button
Functions
Luminance
Image Setup
Color Temp.
Color Boost
Picture Boost
OSD Setup
Extra
Regulatory Compliance FCC, CE
