Adjusting Viewing Angle

For optimal viewing, it is recommended to look at the full face of the monitor, and then adjust the monitor's angle to

your own preference.

Hold the stand so you will not topple the monitor when you change the monitor's angle.

NOTE:

Do not adjust the viewing angle over 23 degrees in order to avoid damage.

Questions and Answers:

Need help?

Do you have a question about the AOC U2790VQ and is the answer not in the manual?

AOC U2790VQ Specifications

General

3D	No
Color depth	10 bit
Pixel pitch	0.3114 x 0.3114 mm
Screen shape	Flat
Backlight type	W-LED
Pixel frequency	170 MHz
Display diagonal	27 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	2160p
Viewable size, vertical	336.31 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	597.89 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	3840 x 2160
Certification	ISO
Product color	Black
Detachable stand	Yes
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Business
Cable lock slot	-
Tilt angle range	-3.5 - 21.5 °
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
HDMI version	1.4/2.0
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Package type	Box
Package depth	185 mm
Package width	703 mm
Package height	362 mm
Package weight	6710 g
VGA cable length	1.8 m
Cables included	AC, HDMI, VGA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	22 W
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
RMS rated power	4 W

Weight and Dimensions
