General| 3D | No |
|---|---|
| Color depth | 10 bit |
| Pixel pitch | 0.3114 x 0.3114 mm |
| Screen shape | Flat |
| Backlight type | W-LED |
| Pixel frequency | 170 MHz |
| Display diagonal | 27 \ |
| Display technology | LCD |
| Native aspect ratio | 16:9 |
| Vertical scan range | 50 - 76 Hz |
| Maximum refresh rate | 60 Hz |
| Horizontal scan range | 30 - 83 kHz |
| Supported video modes | 2160p |
| Viewable size, vertical | 336.31 mm |
| Contrast ratio (dynamic) | 20000000:1 |
| Contrast ratio (typical) | 1000:1 |
| Display number of colors | 1.073 billion colors |
| Viewable size, horizontal | 597.89 mm |
| Display brightness (typical) | 350 cd/m² |
| Supported graphics resolutions | 3840 x 2160 |
| Certification | ISO |
| Product color | Black |
| Detachable stand | Yes |
| Heavy metals free | Hg (mercury), Pb (lead) |
| Market positioning | Business |
| Cable lock slot | - |
| Tilt angle range | -3.5 - 21.5 ° |
| Number of OSD languages | 16 |
| Panel mounting interface | 100 x 100 mm |
| On Screen Display (OSD) languages | CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE |
| HDMI version | 1.4/2.0 |
| DisplayPort version | 1.2 |
| Headphone connectivity | 3.5 mm |
| Package type | Box |
| Package depth | 185 mm |
| Package width | 703 mm |
| Package height | 362 mm |
| Package weight | 6710 g |
| VGA cable length | 1.8 m |
| Cables included | AC, HDMI, VGA |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 22 W |
| Recyclable packaging material | 100 % |
| Mean time between failures (MTBF) | 50000 h |
| Sustainability certificates | RoHS, EPEAT Silver, ENERGY STAR |
| RMS rated power | 4 W |
Weight and Dimensions| Depth (with stand) | 199.7 mm |
|---|---|
| Width (with stand) | 612.6 mm |
| Height (with stand) | 453.2 mm |
| Weight (with stand) | 4700 g |
| Depth (without stand) | 45.3 mm |
| Height (without stand) | 362.1 mm |
| Weight (without stand) | 3000 g |
Describes notational conventions used in the document, including notes, cautions, and warnings.
Explains the usage of icons and bold/italic text for notes, cautions, and warnings.
Provides guidelines and warnings regarding the monitor's power source and connection.
Details safe procedures for installing the monitor, including placement and ventilation.
Provides instructions and precautions for cleaning the monitor's cabinet and screen safely.
Covers miscellaneous safety precautions, including handling unusual smells and environmental factors.
Lists all items included in the monitor packaging, such as cables and accessories.
Step-by-step instructions for attaching or removing the monitor's base stand.
Guidance on how to adjust the monitor's tilt angle for optimal viewing and to prevent damage.
Illustrates cable connections for power and video inputs like HDMI and DisplayPort.
Instructions for attaching the monitor to a wall mount arm, including base removal.
Details the function of the monitor's physical buttons for quick adjustments and menu navigation.
Explains how to activate and use the Clear Vision feature for enhanced image quality.
Detailed settings for contrast, brightness, eco mode, gamma, and dynamic contrast ratio.
Adjusts clock, phase, sharpness, and horizontal/vertical position for picture clarity.
Manages color temperature, DCB mode, and RGB gains for personalized color profiles.
Fine-tunes specific image frame areas for brightness, contrast, and position.
Configures OSD language, timeout, transparency, and break reminder settings.
Accesses advanced options like input selection, auto configuration, and DDC/CI.
Provides options to save current settings and exit the On-Screen Display (OSD) menu.
Introduction to AOC's i-Menu software for adjusting monitor settings via PC.
Details AOC e-Saver software for power management and automatic monitor shutdown.
Explains Screen+ software for desktop splitting and multi-monitor display management.
Solutions for when the monitor's power LED does not illuminate.
Troubleshooting steps for when the monitor displays no image or a 'Input Not Supported' message.
Tips for resolving fuzzy images, ghosting, or shadowing issues on the display.
Addresses issues like picture bouncing, flickering, or wave patterns on the screen.
Solutions for when the monitor remains stuck in an active off-mode.
Troubleshooting steps for displays missing red, green, or blue colors.
Guidance on adjusting image position and size when it's not centered or properly scaled.
Steps to fix color defects, particularly when white appears incorrectly.
Resolving horizontal or vertical disturbances affecting the screen display.
Details monitor specifications including panel, physical, and environmental characteristics.
Lists supported display resolutions, horizontal, and vertical frequencies for various modes.
Details pin configurations for 19-pin and 20-pin color display signal cables.
Explains the Plug & Play DDC2B feature for monitor identity and capability communication.
