Luminance

1 Press MENU (Menu) to display menu.

2 Press

or to select (Luminance), and press MENU to enter.

3 Press

or to select submenu.

4 Press

or to adjust.

5 Press

AUTO to exit.

Contrast 0-100 Contrast from Digital-register.

Brightness 0-100 Backlight Adjustment

Eco mode

Standard

Standard Mode

Text

Text Mode

Internet

Internet Mode

Game

Game Mode

Movie

Movie Mode

Sports

Sports Mode

Uniformity

Mode

Fluctuations in brightness and color on different

parts of a screen are a common phenomenon

among LCD displays. Typical uniformity is

measured around 75%-80%. By enabling AOC

Uniformity feature, display uniformity is

increased to about 95%. This produces more

consistent and true images.

Gamma

Gamma1 Adjust to Gamma 1

Gamma2 Adjust to Gamma 2

Gamma3 Adjust to Gamma 3

DCR

Off Disable dynamic contrast ratio

Enable dynamic contrast ratio

OverDrive

Weak

Adjust the response time.

It could be blur image, if user turns on the

OverDrive in Strong Level.

User can adjust OverDrive level base on user's

preference or turn it off.

Medium

Strong

Off

Questions and Answers:

Need help?

Do you have a question about the AOC U2879VF and is the answer not in the manual?

AOC U2879VF Specifications

General

DDC/CI	Yes
Panel type	TN
Color depth	8 bit
Pixel pitch	0.16 x 0.16 mm
Aspect ratio	16:9
Screen shape	Flat
Pixel density	157 ppi
Backlight type	W-LED
Display surface	-
Pixel frequency	185.58 MHz
Display diagonal	28 \
Surface hardness	3H
Display technology	LCD
Vertical scan range	50 - 76 Hz
Horizontal scan range	30 - 99 kHz
Supported video modes	2160p
Viewable size, vertical	341.28 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Display brightness (peak)	- cd/m²
Display diagonal (metric)	71.12 cm
Viewable size, horizontal	620.93 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3840 x 2160
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Feet color	Black/Silver
Certification	True
Product color	Silver, Black
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Home
Exterior finish type	Gloss
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Tilt angle range	-5 - 24 °
Cable lock slot type	Kensington
Number of OSD languages	16
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.23 W
Power consumption (standby)	0.32 W
Power consumption (typical)	49 W
Operating altitude	0 - 3658 m
Non-operating altitude	3658 - 12192 m
Storage temperature (T-T)	-25 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Package type	Box
Package depth	159 mm
Package width	732 mm
Package height	543 mm
Package weight	5260 g
VGA cable length	1.8 m
Cables included	AC, DisplayPort, HDMI, VGA
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
AMD FreeSync type	FreeSync
AMD FreeSync refresh rate range	30 - 144 Hz
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	153.2 mm
Height (with stand)	468.4 mm
Weight (with stand)	4000 g
Depth (without stand)	- mm
Width (without stand)	659.3 mm
Weight (without stand)	- g
