AOC U2879VF User Manual

5
Power
The monitor should be operated only from the type of power source indicated on the label. If you are not sure
of the type of power supplied to your home, consult your dealer or local power company.
The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will
fit only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug,
have an electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the
safety purpose of the grounded plug.
Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the
monitor from damage due to power surges.
Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate
configured receptacles marked between 20V, 3.25A
The wall socket shall be installed near the equipment and shall be easily accessible.
For use only with the attached power adapter (Only for monitors with power adapter).
Manufacturers:
1) TPV ELECTRONICS(FUJIAN) CO., LTD model :
ADPC2065

AOC U2879VF Specifications

General

DDC/CI	Yes
Panel type	TN
Color depth	8 bit
Pixel pitch	0.16 x 0.16 mm
Aspect ratio	16:9
Screen shape	Flat
Pixel density	157 ppi
Backlight type	W-LED
Display surface	-
Pixel frequency	185.58 MHz
Display diagonal	28 \
Surface hardness	3H
Display technology	LCD
Vertical scan range	50 - 76 Hz
Horizontal scan range	30 - 99 kHz
Supported video modes	2160p
Viewable size, vertical	341.28 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Display brightness (peak)	- cd/m²
Display diagonal (metric)	71.12 cm
Viewable size, horizontal	620.93 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3840 x 2160
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Feet color	Black/Silver
Certification	True
Product color	Silver, Black
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Home
Exterior finish type	Gloss
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Tilt angle range	-5 - 24 °
Cable lock slot type	Kensington
Number of OSD languages	16
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.23 W
Power consumption (standby)	0.32 W
Power consumption (typical)	49 W
Operating altitude	0 - 3658 m
Non-operating altitude	3658 - 12192 m
Storage temperature (T-T)	-25 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Package type	Box
Package depth	159 mm
Package width	732 mm
Package height	543 mm
Package weight	5260 g
VGA cable length	1.8 m
Cables included	AC, DisplayPort, HDMI, VGA
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
AMD FreeSync type	FreeSync
AMD FreeSync refresh rate range	30 - 144 Hz
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	153.2 mm
Height (with stand)	468.4 mm
Weight (with stand)	4000 g
Depth (without stand)	- mm
Width (without stand)	659.3 mm
Weight (without stand)	- g
