3.2 Factroy Preset Timing
VESA MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
+/- 1kHz
Sync
Polarity
Nominal
Frequency
+/- 1 Hz
Sync
Polarity
Nominal
Clock
(MHz)
640x480@60Hz 800x525 31.469 N 59.940 N 25.175
640x480@72Hz 832x520 37.861 N 72.809 N 31.500
VGA
640x480@75Hz 840x500 37.500 N 75.00 N 31.500
800x600@56Hz 1024x625 35.156 N/P 56.250 N/P 36.000
800x600@60Hz 1056x628 37.879 P 60.317 P 40.000
800x600@72Hz 1040x666 48.077 P 72.188 P 50.000
SVGA
800x600@75Hz 1056x625 46.875 P 75.000 P 49.500
1024x768@60Hz 1344x806 48.363 N 60.004 N 65.000
1024x768@70Hz 1328x806 56.476 N 70.069 N 75.000
XGA
1024x768@75Hz 1312x800 60.023 P 75.029 P 78.750
1280x1024@60Hz 1688x1066 63.981 P 60.020 P 108.000
SXGA
1280x1024@75Hz 1688x1066 79.976 P 75.025 P 135.000
1440x900@60Hz 1904x934 55.935 N 59.887 P 106.500
WXGA+
1440x900@60Hz 1600x926 55.469 P 59.901 N 88.750
1680x1050@60Hz 2240x1089 65.290 N 59.954 P 146.250
WSXGA
1680x1050@60Hz 1840x1080 64.674 P 59.883 N 119.000
HD 1920x1080@60Hz 2200x1125 67.500 N 60.000 N 148.500
1280x720@60Hz 1650x750 45.000 P 60.000 P 74.250
***
1280x960@60HZ 1800x1000 60.000 P 60.000 P 108.000
IBM MODES
DOS 640x350@70Hz 800 x 449 31.469 P 70.087 N 25.175
DOS 720x400@70Hz 900 x 449 31.469 N 70.087 P 28.322
MAC MODES
VGA 640x480@67Hz 864x525 35.000 N 66.667 N 30.240
SVGA 832x624@75Hz 1152x667 49.725 N 74.551 N 57.283
XGA 1024x768@75Hz 1328X804 60.241 N 74.927 N 80.000
