13
3. Input/Output Specification
3.1 Connectors
D-sub
Pin No. Description Pin No. Description
1 Red Video 9
＋5V Power
2 Green Video 10 GND
3 Blue Video 11 N/A
4 N/A 12 DDC-Serial Data
5 DDC-Return 13 H-Sync.
6 Red Ground 14 V-Sync.
7 Green Ground 15 DDC-Serial Clock
8 Blue Ground
HDMI
Pin No. Description Pin No. Description
1
HDMI data 2＋
11
HDMI Clock Shield
2
HDMI data 2 Shield
12
HDMI Clock－
3
HDMI data 2－
13
CE remote
4
HDMI data 1＋
14
N/A
5
HDMI data 1 Shield
15
DDC Clock
6
HDMI data 1－
16
DDC Data
7
HDMI data 0＋
17
GND
8
HDMI data 0 Shield
18
＋5V Power
9
HDMI data 0－
19
HP DET
10
HDMI Clock＋
Composite Vedio / S-Video AND Component Vedio Connectors
S-Video (Y/C) : Monitor rear side : 4 Pin Mini-DIN female
Composite Video : Monitor rear side : RCA female
Audio Output : Monitor rear side : RCA female (Red/White) (right channel/left channel)
Audio In : Monitor rear side : PhoneJack (Green)
Headphone : Monitor rear side : PhoneJack (Black)
