Exploded Parts List
V22t
No. Description Q’ty
1 MYLAR HDV22 1
2 BEZEL_INSERT 1
3 BEZEL 1
4 BEZEL LOOP INSERT 1
5 POWER KEY DECO 1
6 POWER BUTTON 1
7 FUNCTION-KEY 1
8 PLAN BUTTON 1
9 SHIELD_COVER_MAIN 1
10 SHIELD_COVER_INVERTER 1
11 BRACKET_HINGE 1
12 HINGE COVER 1
13 SHIELD_MAIN 1
14 SHIELD_INVERTER 1
15 VESA BKT 2
16 REAR COVER 1
17 HINGE 1
18 STAND 1
19 BASE 1
20 FOOT 6
21 BASE DECO 1
22 BASE-BACKET 1
23 INSULATE SHEET 1
24 INSULATE SHEET 1
No. Part No. Description Q’ty
25 IR BOARD 1 30 0Q1G 930 8120 SCREW FOR IR BOARD AND BEZEL 2
26 KEY BOARD 1 31 0Q1G 340 8120 SCREW FOR BKT AND BEZEL 5
27 MAIN BOARD 1 32 0M1G1030 6120 SCREW FOR MAIN BOARD AND INVERTER BOARD 6
28 INVERTER BOARD 1 33 0Q1G 140 8120 SCREW FOR BKT AND BASE 3
29 PANEL 1 34 001G6022500 SCREW FOR STAND BOTTOM AND BASE 1
