AOC V22t User Manual

57
R921 061G1206105 JF RST CHIPR 1 MOHM +-5% 1/4W FENGHUA
R907 061G1206229 RST CHIPR 2.2 OHM +-5% 1/4W
R906 061G1206434 JF RST CHIPR 430KOHM +-5% 1/4W FENGHUA
R922 061G1206434 JF RST CHIPR 430KOHM +-5% 1/4W FENGHUA
R908 061G1206470 RST CHIPR 47 OHM +-5% 1/4W
R917 061G1206472 RST CHIPR 4.7K OHM +-5% 1/4W
R904 061G1206473 F RST CHIPR 47KOHM +-5% 1/4W FENGHUA
R912 061G1206510 RST CHIPR 51 OHM +-5% 1/4W
R913 061G1206510 RST CHIPR 51 OHM +-5% 1/4W
R923 061G1206510 RST CHIPR 51 OHM +-5% 1/4W
R918 061G12065100FY RST CHIPR 510 OHM +-1% 1/4W
R901 061G1206684 RST CHIPR 680K OHM +-5% 1/4W
R902 061G1206684 RST CHIPR 680K OHM +-5% 1/4W
R903 061G1206684 RST CHIPR 680K OHM +-5% 1/4W
R919 061G1206976 1F RST CHIPR 9.76 KOHM +-1% 1/4W
C911 065G0805103 32 CAP CHIP 0805 10NF K 50V X7R
C922 065G0805104 32 CAP CHIP 0805 0.1UF K 50V X7R
C908 065G0805104 32 CAP CHIP 0805 0.1UF K 50V X7R
C923 065G080510522K 3 CAP CHIP 0805 1U 25V X7R +/-10%
C915 065G0805223 32 GP MLCC 0805 22NF J 50V X7R
C912 065G0805331 32 CHIP 330P 50V X7R 0805
C914 065G120622272K Y CAP CHIP 1206 2200PF K 500V X7R
C920 065G120647522K T CAP CHIP 1206 4.7UF K 25V X7R
IC904 056G 158 12 KIA431A-AT/P TO-92
R911 061T152M62852T RST MOFR 0.62 OHM +-5% 2WS
C906 067G 2154707NT KY50VB47M-TP5 6.3*11
F901 084G 56 4 B FUSE 4A 250V
J902 095G 90 23 JUMPER WIRE
J901 095G 90 23 JUMPER WIRE
715G 901 1 15 POWER PCB FR-1 S/S 54.1X104MM
709G 901 QA001 CONSUMPTIVE ASS'Y
C926 065G 1K222 5T6213 CER CAP 2200PF K 1KV TDK
J903 095G 90 23 JUMPER WIRE
R914 061G1206434 JF RST CHIPR 430KOHM +-5% 1/4W FENGHUA
709G 901 QS001 CONSUMPTIVE ASS'Y
052G 2191 A PAPER TAPE
C916 065G120622272K Y CAP CHIP 1206 2200PF K 500V X7R
R967 061G1206434 JF RST CHIPR 430KOHM +-5% 1/4W FENGHUA
R986 061G0805103 JT RST CHIPR 10K OHM +- 5% 1/8W TZAI YUAN
GND2 Q09G6014 1 PIN
GND1 Q09G6014 1 PIN
GND3 Q09G6014 1 PIN
Q40G375B615 3B RATING LABEL
Q52G 1205106 CU FOIL
T901 S80GL19T507V X'FMR 2MH
W33G4477 B T 30 TOP COVER
W33G4478 B T BOTTOM COVER
705GQ851001 OIL FOR DISAPPEAR ASS'Y
705GQ857032 Q901 ASS"Y
Q901 057G 667508 MOSFET STF14NM65N 12/650V TO-220FP
0M1G 930 6120 SCREW
