AOLBEA P100 - Body-Worn Camera Overview

- 3 -
Body-Worn Camera Overview>>
FRONT Back Left Right
Top
1
8
10
9
13
22 23
14
21
24
18
19
20
15
16
17
11 12
2
3
4
5
6
7
1. Photosensitive
2. HD Camera
3. Microphone
4. Flashlight
5. Speaker
6. Laser Point
7. LED illumination Light
8. Belt Clip
9. Screen
10. Menu/Back Button
11. Left/Up Button
12. Right/Down Button
13. OK/Preview Button
14. Walkie-Talkie(optional)
15. Flashlight/IR CUT Button
16. Laser/Alarm Button
17. Reset Button
18. Video Recording
/Snapshots/One-key Video
Recording Button
19. Photo Button
20. USB interfere Port
21. Power Button
22. Status Indicator Light
23. Recording Indicator Light
24. Audio Recording
/Lock Video files Button
