The AK77-600GN provides an HT UAGPUT H 8X slot. The AGP 8X is a bus interface targeted for high-performance 3D graphic. AGP
supports only memory read/write operation and single-master single-slave one-to-one only. AGP uses both rising and falling
edge of the 66MHz clock, for 4X AGP, the data transfer rate is 66MHz x 4bytes x 4 = 1056MB/s. AGP is now moving to AGP 8X
mode, which is 66MHz x 4bytes x 8 =2.1GB/s.
Warning: It is strongly
recommended not to
install a 3.3V AGP card,
which is not supported by
VIA
P
®
P
Apollo KT600
chipsets.
