AOX AOX-Q Series User Manual

- 5 -
4.2 Standard Technical Parameter
Shell
Enclosure :IP67,NEMA4, Exd II CT5
Power
Standard:220VAC/1ph
Optional:110VAC/1ph, 380V/440V/3ph,50/60Hz, ±10%
24VDC/110VDC/220VDC
Motor
Asynchronous motor
Limit switch
2×Open/ Close, SPDT,250VAC 10A
Auxiliary limit switch
2×Open/ Close, SPDT,250VAC 10A
Torque switch
Close/Open, each 1, SPDT,250VAC 10A
Except AOX-Q-005/008/010
Travel
90°±10°
0°
～
270°
Fail safe/
Operating temperature
Internal-placed thermal protection, Open 115
℃
±5
℃
/Close 97
℃
± 5
℃
Indicator
Continuous position indicator
Manual operate
Declutching mechanism, operate by handwheel
Self-locking device
Self-locking by worm and worm gear
Mechanical limit
2 × external adjustable stopper
Space heater
30W(110V/220VAC)
Conduit entry
2 × PF 3/4”
Ambient temperature
-20℃～+70℃
Lubrication
Grease moly（EP type）
Material
Steel, Aluminum alloy, Aluminum bronze,Polycarbonate
Ambient humidity
Max 90
％
RH
Non-Condensing
Anti-vibration
X Y Z 10g,0.2～34 Hz,30 minutes
External coating
Dry powder, Epoxy polyester,high anti-corrosion
