AOX AOX-Q Series User Manual

- 7 -
6. General Drawing
6.1 AOX-Q-005~120 Appearance and installation dimension
Picture 1 Unit: mm
Model
X
Y
Z
ΦA
ΦB
N-C
ΦD
N-E
ΦF
G
H
AOX-Q-005
260
161
236
Φ90
Φ70
4-M8
Φ
20
140
40
AOX-Q-008
260
161
236
Φ90
Φ70
4-M8
Φ20
140
40
AOX-Q-010
260
161
236
Φ90
Φ70
4-M8
Φ20
140
40
AOX-Q-015
351
227
270
Φ125
Φ102
4-M10
Φ70
4-M8
Φ22
140
45
AOX-Q-020
351
227
270
Φ125
Φ102
4-M10
Φ70
4-M8
Φ22
140
45
AOX-Q-030
367
242
290
Φ150
Φ125
4-M12
Φ102
4-M10
Φ
35
140
55
AOX-Q-050
367
242
290
Φ150
Φ125
4-M12
Φ102
4-M10
Φ35
140
55
AOX-Q-060
367
242
290
Φ150
Φ125
4-M12
Φ102
4-M10
Φ35
140
55
AOX-Q-080
410
276
330
Φ180
Φ140
4-M16
Φ140
4-M12
Φ45
140
65
AOX-Q-120
410
276
330
Φ180
Φ140
4-M16
Φ140
4-M12
Φ45
140
65
