AOX AOX-Q Series User Manual

- 8 -
6.1 AOX-Q-150~600 Appearance and installation dimension
Picture 2
Unit:mm
Model
X
Y
Z
ΦA
Φ
B
N-
C
Φ
D
N-E
Φ
F
G
X1
X2
AOX-Q-150
410
276
330
Φ285
Φ165
4-M18
Φ140
4-M16
Φ
45
140
454
696
AOX-Q-200
410
276
330
Φ285
Φ165
4-M18
Φ140
4-M16
Φ
45
140
454
696
AOX-Q-300
410
276
330
Φ285
Φ165
4-M18
Φ140
4-M16
Φ45
140
454
696
AOX-Q-400
410
276
330
Φ285
Φ165
4-M18
Φ140
4-M16
Φ45
140
454
696
AOX-Q-500
410
276
330
Φ285
Φ165
4-M18
Φ140
4-M16
Φ45
140
454
696
AOX-Q-600
410
276
330
Φ285
Φ165
4-M18
Φ140
4-M16
Φ45
140
454
696
