Apache RTR 180 User Manual

7. SERVICE INFORMATION
VALVE & VALVE GUIDE
Unit :
S.No
Description
Standard
Service li it
Inlet
0.06
0.08
1 Valve clearance
Exhaust
0.08
0.10
CYLINDER, PISTON & RINGS PISTON
Unit : mm
S.No
Description
Standard
Service limit
1
Cylinder to piston clearance
.
0.025
0.120
0.020
-
2
62 500
-
62 515
62.610
Cylinder bore diameter
3
Piston dia (measure 10mm from skir end)
62.475
-
62.490
62.380 - 62.395
4
Cylinder distortion
0.05
Top
0.200
-
0.350
0.7
5
Ring piston closed end gap
2 nd
0.350 - 0500
0.7
Top
0.015
-
0.045
0.12
6
Ring groove clearance
2 nd
0.015
-
0.045
0.10
Top
0.8005 - 0.820
__
7
Ring piston - groove width
2 nd
0.8005 - 0.820
__
Top
0.775
-
0.790
__
8
Ring thickness
2 nd
0.775
-
0.790
__
CLUTCH
Unit : mm
S.No
Description
Standard
Service limit
1
Lever clutch free play at l v r nd (in cold condition of engine)
5 -10
15
2
Plate clutch drive claw width
15.750
-
15.850
15.3
3
Spring clutch free length
29.5
28.8
8. FREE / PAY SERVICES & WARRANTY
Free & Pay s rvice sch dules, Free service re-imbursement charges, Warranty terms and conditions and
warranty labour charg s are same as that of Apache 150 cc / RTR 160 cc.
-10-

Apache RTR 180 Specifications

General

Engine Displacement	177.4 cc
Engine Type	4-stroke, Single Cylinder
Max Torque	15.5 Nm @ 7000 rpm
Fuel System	Carburetor
Cooling System	Air Cooled
Transmission	5-Speed
Front Brake	Disc
Fuel Tank Capacity	12 liters
Bore x Stroke	62.5 mm x 57.8 mm
Compression Ratio	9.5:1
Front Suspension	Telescopic Forks
Front Tyre	90/90-17
Rear Tyre	110/80-17
Overall Length	2085 mm
Overall Width	730 mm
Wheelbase	1326 mm
Ground Clearance	165 mm
Seat Height	800 mm
Max Power	17.03 PS @ 8500 rpm
Ignition	Digital
Starting	Electric Start
Clutch	Wet multi-plate
Frame Type	Double cradle
