Apache RTR 180 User Manual

9. PRE - DELIVERY INSPECTION (PDI)
PDI CHECK LIST - Apache RTR 180
Sl.No
Description
Not OK ( )
1 Transit Damages
1.1
Front fender
1.2
Head Lamp / Housing front / Visor
1.3
TSL Indicators LH & RH
1.4
Clutch & brake levers position & scratch
1.5
Damper handlebar Scratches
1.6
Fuel tank assembly
1.7
Fuel tank covers
1.8
Cover frames / Tail covers
1.9
Pillion handle
1.10
Seat
1.11
Silencer guard (Front & Rear)
1.12
Saree guard
1.13
Others (if any specify)
2
Missing Items if any
2.1
Split pins
2.2
Rider / Pillion footrest rubber
2.3
Any other items
3
Fasteners Tightness
3.1
Front Axle Nut
3.2
Rear Axle Nut
3.3
Rear shock absorber mou ti g uts
3.4
Swing Arm Nut
3.5
Engine mounting bolts
3.6
Footrest mouting bolts
3.7
Damper handle bar scr w
4
Standard Checks
4.1
Front & Rear Wheel for free rotation
4.2
Front & Rear Wheel for any noise
4.3
Key function - Ignition, tank, steering, cover frame
4.4
Digital speedometer - Self check
4.5
Mode and Set switch operation / function (Check
Odo, trip meter A&B and digital clock)
4.6
Fu l gauge and warning light function
4.7
Clutch cable operation / free play
4.8
Centre / side stand operation
4.90
Drive chain slackness
-11-
Remarks

Apache RTR 180 Specifications

General

Engine Displacement	177.4 cc
Engine Type	4-stroke, Single Cylinder
Max Torque	15.5 Nm @ 7000 rpm
Fuel System	Carburetor
Cooling System	Air Cooled
Transmission	5-Speed
Front Brake	Disc
Fuel Tank Capacity	12 liters
Bore x Stroke	62.5 mm x 57.8 mm
Compression Ratio	9.5:1
Front Suspension	Telescopic Forks
Front Tyre	90/90-17
Rear Tyre	110/80-17
Overall Length	2085 mm
Overall Width	730 mm
Wheelbase	1326 mm
Ground Clearance	165 mm
Seat Height	800 mm
Max Power	17.03 PS @ 8500 rpm
Ignition	Digital
Starting	Electric Start
Clutch	Wet multi-plate
Frame Type	Double cradle
