Apache RTR 180 User Manual

9. PRE - DELIVERY INSPECTION (PDI)
4.10 Rear fender alignment
4.11 Steering operation
4.12 Front & Rear brake play
4.13 Front & Rear Tyre Pressure
4.14 Engine / Gear box Oil Level - Dipstick
4.15 Gear lever & brake pedal position w.r.t rider footrest
5 Start the Engine after petrol in tank
5.1
Startability
5.2
Kick / Self starter functioning
5.3
Ignition cut off / Kill switch function
5.4
Cold recovery - Throttle response
5.5
Tachometer function
5.6
Oil / Fuel leak if any
5.7
Any abnormal Noise
6
Electrical check - Engine running
6.1
Head lamp & Parking lamp ON / OFF
6.2
High beam Low beam & Focus
6.3
Rear combination lamp - Brake & Tail (LED)
6.4
Speedo panel bulbs (LED)
6.5
Turn signal lamp (Front & Rear)
6.6
Battery terminal - Jelly application
6.7
Horn function
7
Road Trial
7.1
Gear Shifting
7.2
Front & Rear Brake Effe
ctiveness
7.3
Speedo / Odo / trip m t
r display and function
7.4
Suspension - Front & Rear
7.5
Steering shake - On braking
7.6
Idling RPM stability (Use Tachometer to evaluate)
7.7
Any other abnormality
8
Accessories fitment
8.1
Mirrors alignment
8.2
Tool kit
9
Any other Observations (Specify)
9.1
-12-

Apache RTR 180 Specifications

General

Engine Displacement	177.4 cc
Engine Type	4-stroke, Single Cylinder
Max Torque	15.5 Nm @ 7000 rpm
Fuel System	Carburetor
Cooling System	Air Cooled
Transmission	5-Speed
Front Brake	Disc
Fuel Tank Capacity	12 liters
Bore x Stroke	62.5 mm x 57.8 mm
Compression Ratio	9.5:1
Front Suspension	Telescopic Forks
Front Tyre	90/90-17
Rear Tyre	110/80-17
Overall Length	2085 mm
Overall Width	730 mm
Wheelbase	1326 mm
Ground Clearance	165 mm
Seat Height	800 mm
Max Power	17.03 PS @ 8500 rpm
Ignition	Digital
Starting	Electric Start
Clutch	Wet multi-plate
Frame Type	Double cradle
