Apache RTR 180 User Manual

1. GENERAL INFORMATION
Rear suspension
Monotube inverted gas filled 5 step adjustable shocks
with rectangular swing arm
Steering angle
41°
com
Caster angle
25.5°
Trail length
84.3 mm
Turning radius
2150 mm
Brakes
Front
Hand operated, 270 mm petal disc
Rear
Foot operated, 200 mm petal disc
Tyre size
Front
90 / 90 x 17 Tubeless
Rear
.
110 / 80 x 17 Tubeless
Tyre pressure
NexGenBikes
Solo
Front
1.75 kg/cm² (25 PSI)
Rear
2.00 kg/cm² (28 PSI)
Dual
Front
1.75 kg/cm² (25 PSI)
Rear
2.25 kg/cm² (32 PSI)
ELECTRICAL
Type
AC generator
Ignition system
IDI - Dual mode digital ignition
Sparkplug
BOSCH UR5DDC - twin electrode
Battery type
12V 9 Ah
Body earthing
Negative
Generator
Fly wheel magneto 12V 100W
Head lamp
Halogen HS 12V 35/35W
Position lamp
12V 4W x 2
Tail lamp / Brake lamp
LED indicators ( 0.5W / 3.5W )
Turn signal lamp
12V 10W X 4
Number plate lamp
12V 4W X 1
Instrument panel
LCD / LED indicators
Horn type
12V DC x 2
Fuse
12V 10A x 1
CAPACITIES
Fuel tank including reserve
16 litres
Reserve
2.5 litres
Front fork oil (grade)
IOC teleshockab oil
Front fork oil (qty)
140 ± 2.5 ml
Engine cum transmission oil (grade)
4T oil
Engine cum transmission oil (qty)
After draining
1000 ml
Aft r disassembly
1100 ml
ote : 1. Specifications are subject to change on account of continuous improvements in the product.
2. For details on exclusive parts and part numbers, refer page No
of this manual.
-3-

Apache RTR 180 Specifications

General

Engine Displacement	177.4 cc
Engine Type	4-stroke, Single Cylinder
Max Torque	15.5 Nm @ 7000 rpm
Fuel System	Carburetor
Cooling System	Air Cooled
Transmission	5-Speed
Front Brake	Disc
Fuel Tank Capacity	12 liters
Bore x Stroke	62.5 mm x 57.8 mm
Compression Ratio	9.5:1
Front Suspension	Telescopic Forks
Front Tyre	90/90-17
Rear Tyre	110/80-17
Overall Length	2085 mm
Overall Width	730 mm
Wheelbase	1326 mm
Ground Clearance	165 mm
Seat Height	800 mm
Max Power	17.03 PS @ 8500 rpm
Ignition	Digital
Starting	Electric Start
Clutch	Wet multi-plate
Frame Type	Double cradle
