− from the film keypad located on the front panel (in AR500 and AR503 the buttons are accessible after the

front glass is taken out)

− through the RS485 or the AR955 programmer and the ARSOFT-WZ1 free software (Windows

2000/XP/Vista/7/8)



software and the AR955 programmer that enables viewing the measured value and quick configuration single

or ready sets of parameters pre-saved on the computer in order to be used again, for example in other meters

of the same type (duplication of configuration)



panel enclosure (on the front side: IP65 - AR517, IP54 - AR500, AR503, AR518)



optionally (to be selected at the time of order): 24 V AC/DC power supply, analog output 0/2÷10 V and RS485

interface (does not apply to AR500)



high accuracy, long-term stability, and immunity to interferences;



available accessories:

− AR955 programmer

− RS485/USB converter

NOTE:

Before starting to work with the meter, you must become familiar with these operating instructions,

properly prepare the electrical system and the mechanical system, and correctly configure the parameters.

4. CONTENTS OF THE SET



a meter with grips for installation in a panel window



operating instructions



a warranty card

5. TECHNICAL DATA

1 universal input (set with parameter 0: inP )

measurement range

Pt100 (RTD, 3

or 2

wire)

200

850

°C

Ni100 (RTD, 3

or 2

wire)

170

°C

Pt500 (RTD, 3

or 2

wire)

200

620

°C

Pt1000 (RTD, 3

or 2

wire)

200

520

°C

thermocouple J (Fe

CuNi)

800

°C

thermocouple K (NiCr

NiAl)

1,200

°C

thermocouple S (PtRh 10

Pt)

1,600

°C

thermocouple B (PtRh30PtRh6)

300

1,800

°C

thermocouple R (PtRh13

Pt)

1,600

°C

thermocouple T (Cu

CuNi)

350

°C

thermocouple E (NiCr

Ni)

820

°C

- thermocouple N (NiCrSi-NiSi

)

1,300

°C

current (R

= 50 Ω)

0/4

voltage (R

= 110 kΩ )

voltage (R

> 2 M Ω)

resistance (3

or 2

wire)

2,500

remote data display (through the RS485 or PRG port)

1999

9999

Response time

(10 ÷ 90%)

0.25 ÷ 3 s (programmable with parameter 1: FiLt )

Resistance of leads

(RTD, Ω)

< 25 Ω (for each line)

Resistance input current

(RTD, Ω)

400 μA (Pt100, Ni100), 200 μA (others)
