35: ctoP upper correction -4.00÷0.50 mA/V changes of0.05 mA/V
for 20mA or 10V
IV. PID ALGORITHM CONFIGURATION (1÷3), submenu Pid1 ÷ Pid3 , in the 3 groups Pid1/2/3 there are the same
parameter sets with different indices and numbering in the names, description in chapters 9.3÷9.5
36/40/44: tun1/2/3 type of
PID tuning (autotuning)
0: oFF =disabled, 1: Auto =smart logic, 2: S tEP = step response method
(fast), 3: oSct = oscillation method (longer), chapter 9.4
oFF
37/41/45: Pb1/2/3 Pb proportional band 0.1 ÷ 1800 or 1 ÷ 9999 units (2) 1.0 °C
38/42/46: ti1/2/3 integral time Ti
0÷ 3600 s, PID algorithm integral action time, 0 turns off the
integral element
0 sec.
39/43/47: td1/2/3 derivative time Td
0 ÷ 999 s, PID derivative action time, 0 turns off the derivative
element
0 sec.
V. CONFIGURATION OF THE PROCESS CONTROLLER (programmable operating characteristic, ramping), submenu
ProG , description - chapter 9.6
48/53/58: tYP1/2/3 stage
type 1/2/3
0: Grti
stage consisting of 2 segments: reaching the setpoint 11:
SEt1/2/3 with the slope defined by parameter 49: GrA1/2/3
(ramping) and countdown (50: tiM1/2/3) after reaching it
Grti
1: tiME countdown of time after reaching the setpoint SEt1/2/3 (± H /2)
2: toti
countdown of time for the entire stage (regardless of the
setpoint)
3: EndL
continuous - no time limit
4: StoP
end - the last stage of the program, available only for stage 2/3
49/54/59: GrA1/2/3 slope
of the segment of the
stage 1/2/3
pace of changes (gradient) for the 1st segment of the type stage Grti ,
ramping,
-
30.0 ÷ 30.0 °C/min or -300 ÷ 300 units/min (2)
1.0 °C/min
50/55/60: tiM1/2/3 time for stage
1/2/3
0 ÷ 1440 min, duration of the segment for the stage with
countdown
60 min
51/56/61: PSE1/2/3 control
algorithm for step 1/2/3
1: onof =ON-OFF with hysteresis, 2/3/4: Pid1/2/3 =PID with parameter set
1/2/3 (chap. 9.3, not recommended for the stage Grti - gradient may disturb
PID operation )
onof
52/57/62: ASt1/2/3 state of
the auxiliary output during
stage 1/2/3, 63: AStE after
the completion of stage 3
1: oFF = disabled, 2: on = enabled, 3: hAnd = manual mode with a set output
signal level (parameter 67: HSEt ), selection of the auxiliary output (1/2/3) is
defined by the parameter 9/16/23: ctY1/2/3 = PrGA
oFF
VI. KEYS, ACCESS OPTIONS AND OTHER CONFIGURATION PARAMETERS, submenu othE
64: FunF function
of [F] key
65: Funb function of the
binary input BIN
66: FunS additional
function of the [SET] key
1. detailed description in
chapter 7.1)
2. values 3÷8 ( quick
manual mode) interrupts
and resets the tuning and
0: nonE
inactive - device status (description,
chapter 7, point a)
nonE
1: Set3
step change of the setpoint with the set of parameters for outputs
1 and 3 (day = 11: Set1 /night = 25: Set3), both outputs work the
same (copy)
2: bLoc
keyboard lock , messages bLoF (stop)/ bLon (start, default)
3: hd1A
5: hd2A
7: hd3A
unconditional manual
mode for the output
1/2/3 with the output
signal level (MV) set by
parameter 67:HSEt ,
messages hnd1/2/3
(start)/ hoF1 /2/3 (stop)
start (unchanged) with an initial value
for 67: HSEt taken from the current
automatic control mode
4: hd1w
6: hd2w
8: hd3w
start (step) with the preset value of
parameter 67: HSEt
9: cLEA
(also
10/11)
deleting errors and alarm memory (LATCH) of the STB safety
controller with the message cLEA or none (when there are no
errors and alarms)
