APART REVAMP4100 - Technical Specifications; Physical and Power Specifications

Instruction manualREVAMP4100
13
Technical specifications
19” (483 mm wide) rack mounting yes
Height rack units in U
(1U = 44 mm)
1
Depth (built-in) 230 mm
Depth (incl. front) 239 mm
Power supply 100 - 254 VAC / 50 - 60 Hz
Power consumption (max) 500 W
Output power RMS @ 4 ohms 4 x 100 W
Output power RMS @ 8 ohms 4 x 50 W
Dynamic output power @ 4 ohms 4 X 110 W
Output power bridged @ 8 ohms 2 x 200 W
Dynamic output power bridged @
8 ohms
2 x 225 W
Minimum load impedance 4 ohms
8 ohms in bridged mode
Output channels 4
Input sensitivity 0 dBV / 1 V RMS
Input impedance 22 kohms
Line inputs balanced 4 on euroblock
Line inputs unbalanced 8 (4 x cinch with pass-through)
Frequency response 20 - 22 kHz +0 / -3 dB
S/N ratio >98 dB A-weighted
Protection circuits over current
over temperature
DC offset
