14. Channel 1 speaker output on 2 pole euroblock connector.
15. Channel 4 unbalanced input and link cinch connector: connect
the line level input signal for channel 4 here. Line level is 0 dBV.
Input and link connector are internally connected 1 on 1.
16. Channel 3 unbalanced input and link cinch connector: connect
the line level input signal for channel 3 here. Line level is 0 dBV.
Input and link connector are internally connected 1 on 1. This
connector is also used in bridge mode.
17. Channel 4 balanced input on 3 pole euroblock connector.
18. Channel 3 balanced input on 3 pole euroblock connector: this
connector is used in bridge mode.
19. Channel 2 unbalanced input and link cinch connector: connect
the line level input signal for channel 2 here. Line level is 0 dBV.
Input and link connector are internally connected 1 on 1.
20. Channel 1 unbalanced input and link cinch connector: connect
the line level input signal for channel 1 here. Line level is 0 dBV.
Input and link connector are internally connected 1 on 1. This
connector is also used in bridge mode.
21. Channel 2 balanced input on 3 pole euroblock connector.
22. Channel 1 balanced input on 3 pole euroblock connector: this
connector is used in bridge mode.
23. Mains inlet: connect the mains power cord here.
