Apator Metra E-ITN 40 User Manual

E-ITN 40
Manual for installation service and operation M2021/8a EN
4. OPERATION MODES OF ALLOCATOR
4.1. OPERATION MODES
The allocator can be in four operation modes:
• working mode
• error mode
4.2. SUBMENU NAVIGATION
The allocator contains a simple submenus (depending on current operation mode), that allow to obtain
additional informations or perform other activities.
To switch between individual items of menu, push the button briefly. To enter the submenu, choose relevant
item and hold the button (approximately 2 seconds) until --A-- appears on LCD. When you release the
button, designation of the 1
st
submenu item appears. Move in menu by short presses of the button. If the
button is not pushed for 30 seconds, the LCD returns to the main menu.
Activation process of item is the same as entering the submenu. Find the relevant item and hold the button
(for approximately two seconds), till notice --A -- on the LCD appears.
Movement in options is the same – briefly press the button. Selected option confirmation as well – by long
(approx. 2 s) press of the button, till notice --A-- appears on LCD.
4.3. WORKING MODE
In working mode, allocator performs temperature measurement, calculates the increase of valuecal (if
measurement conditions are met), transmits measured data, updates real-time and makes some other
actions in regular intervals.
4.3.1. Menu structure in working mode
If nothing is displayed press the button briefly.
Data shown on display.
Basic:
• · Serial number of allocator (scrolling – moves 1 character per 1 sec., starts and ends with a
space)
· Start of billing period (e.g.: u01.02.)
o In submenu allocator test, error code, date of error, reading countdown (in sec).
· Consumption for current annual billing period (e.g. 65534)
· Consumption for past annual billing period (e.g. 65534
SM
)
o In submenu annual consumption for year -2 to -5 year, switching by pressing button, shows
value: scrolls 2018-2014
· Consumption for current monthly billing period (e.g. 3.2.7.6.7)
· Consumption for past monthly billing period (e.g. 3.2.7.6.7
SM
)
o In submenu consumption for -2 to -24 month, switching by pressing button, shows values:
scrolls 12.2019.-1.2018 and for 4 seconds a value shows e.g. 3.2.7.6.7
Optional data (sample unit shows all)
· Power of radiator (e.g. 1000.)
· Kc value (e.g. 1.000)
11 / 22
