3.0 Presentation
3.1 400VA UPS—front panel
Site Wiring
Fault light
see Sec. 4.6
Option
switches
see Sec. 5.4
100 & 120 Vac versions
220/230/240 Vac version
3.2 400VA UPS—rear panel
Front-panel indicators
see Sec. 5.1, 5.2.1, 5.2.2
all versions
Test
button
see Sec. 5.2
UPS Enable
switch
Circuit
breaker
IEC 320
power inlet
Computer
Interface port
see Sec. 6.4
NEMA 5-15R
receptacles
IEC 320 output
couplers
Accessory
load outlets
Master
load outlet
