How discharge water is disposed via Air-Gap faucet:
Discharge water is routed through the Air-Gap faucet prior to being drained off into the standard
drainpipe outlet. The 1/4” BLACK waste water line from the RO system will discharge through the
1/4” RED line to the Air-Gap faucet. The drain water will then flow back down the 3/8” BLACK
discharge water line of the Air-Gap faucet to your drain pipe.
Pure water output flow:
After the Air Gap faucet is installed, the RO pure water output line will flow from the Stage-5 filter,
through the BLUE line of the Air-Gap faucet, to the dispensing faucet.
* * * End AirGap Faucet Installation * * *
