MTX-R 2nd Stage Maintenance Manual
Table 4 - Torque Specications
Table 5 - Test Bench Specications
TEST CONDITION ACCEPTABLE RANGE
Opening Effort
High Pressure > 50 Bar Gauge (725 psi) Medium
Pressure 9.5 ± 0.5 Bar (137 ± 7.25 psi)
+1.9” to +2.1”.H²o
(4.7 to 5.2 mbar)
External Leak
High Pressure > 50 Bar Gauge (725 psi) Medium
Pressure 9.5 ± 0.5 Bar (137 ± 7.25 psi)
No Leaks Allowed
PART NUMBER DESCRIPTION / KEY NUMBER TORQUE
AP2004S Heat Exchanger 3 Nm / 2.2 ft/lb
AP0198/DSW Double Swivel 3/8” Flexi 5 Nm / 3.7 ft/lb
