7. Technical Specifications
Item
Specifications
Power Supply
60W, DC 24V, 2.5A
Power Adapter
DELTA ELECTRONICS, Model No.: MDS-060BAS24 A
Input: AC 100~240VAC, 50/60Hz,1.5-0.75A
Output rating: 24Vdc, 2.5A, 60W
Pressure Range
4 –20 cmH
2
O (adjustable in 0.5 cmH
2
O increments)
Ramp Time
0 – 45 minutes (adjustable in 5-minute increments)
Ramp Starting Pressure
4 cmH
2
O to therapy pressure (adjustable in 0.5 cmH
2
O increments)
Operating Altitude
up to 8,000 ft (2,438 m) when the pressure is set at 4-18 cmH
2
O but
limited to 5,000ft (1,524m) when the pressure is set at 18.5 - 20 cmH
2
O
Dimensions (W x D x H)
16.5 x 19.7 x 17.6 cm
Weight
1.14 kg
Sound Level
< 28 dBA at 10 cmH
2
O, 1 metre distance
Water Capacity
300ml
Heater Settings
1 to 6 from 40°C-70°C
Pressure Drop
0.2cmH
2
O @ 60LPM
Humidity Output:
≥ 10 mgH
2
O/L
(Ambient temperature: 23°C ± 2°C & Relative humidity: 60% ± 15%)
Environment
Temperature
Operating: +5°C to +35°C (+41°F to +95°F)
Storage: -15°C to 50°C (+5°F to +122°F)
Shipping: -15°C to 70°C (+5°F to +158°F)
Humidity
Operating: 15%RH to 95%RH non-condensing
Storage: 10%RH to 90%RH non-condensing
Shipping: 10%RH to 90%RH non-condensing
Classification
Class II
Type BF, Applied Parts: Mask
Not suitable for use in the presence of a flammable anaesthetic mixture
IP21: Protected against solid foreign objects of 12.5 mm and greater;
Protected against vertically falling water drops.
Continuous operation.
Note: the manufacturer reserves the right to modify the specifications without notice.
