Connections & Installation
LED Status Description
Outlet Status
(Green LED)
Off
Voltage is turned off to the
outlet.
On
Voltage is applied to the
outlet
RDY (Ready)
Off
No power applied to the
unit, rear jumper removed
(EPO), or unit inoperable.
Green Operating normally
Blinking
Normal communications
with LAN module or RS-
232 ports.
LOCAL On
In local mode. Start button
on front panel enabled.
REMOTE On
In remote mode. External
communications enabled.
CH1 (Upper left)
Off
No power applied to the
unit, or LAN module inoper-
able.
Green
Normal operation of LAN
module once booted up.
Green blinking
Normal operation of LAN
module when communicat-
ing.
LNK (Upper right)
Off
No link or connection to a
network.
Green Network link valid.
DIA (Lower left)
Off Unit operating normally
Red or blinking
Diagnostic failure. Contact
factory for further informa-
tion.
CH2 (Lower right)
Off Operating normally
Yellow or Blinking
CH2 active, consult with
factory for further informa-
tion.
1
2
3
4
5
6
7
8
Figure 4.4 LED Descriptions
