Installation and Operation Manual
ECN: 003155
Date: 06/4/2013
4
AC-SmartStart-7608-Series_IOM Rev 04
Technical Specications
3.0 Technical Specications
Input
Power Entry Connector IEC 320/C14, C20, or attached power cord
Nominal input voltage
120VAC ±10% for Models with “12” in the 9th and 10th
digit of the part number.
230 VAC ± 10% for Models with “24” in the 9th and 10th
digit of the part number.
Input frequency 47 – 63 Hz
Input current
15A, 20A or 30A* maximum per input
(120VAC models)
7.5A, 15A, 20A or 30A* maximum per input
(230VAC models)
*Note: Single input configuration only
Output
Outlet Connectors (8) NEMA 5-15R, (8) NEMA 5-20R or (8) IEC 320/C13
Load Current
15A or 20A maximum per outlet group
(120VAC models)
7.5A or 10A maximum per outlet group
(230VAC models)
Maximum load current of all receptacles combined within
an outlet group, consult factory for other current ratings.
Environmental
Operating temperature 0-40°C (32-104°F)
Operating humidity 0-95% (non condensing)
Operating elevation 0-10,000 ft (0-3048m)
Communication
• Telnet or WEB Browser using optional LAN module
• RS-232: front panel DB-9F or DB-9M connector
• RS-485/RS-422: rear panel RJ-11 connector
(Caution: Do not connect this jack to a telephone network.)
• SNMP
• GUI (Graphical User Interface)
Auxiliary Connections
• Two input connections to generate messages. Make or break contact
between two points on connector. 28 to 16 AWG solid or stranded jumper wire.
• Two Full sets of dry contacts (c, no, nc) rated 2A max, 250VAC max. (60 watts max)
• Optional E-STOP connection. Make or break contact between two points on
connector. 28 to 16 AWG solid or stranded jumper wire.
• Optional temperature sensor connection.
Physical
• Unit height: 1U, 1.75 inches (4.44cm)
• Unit width: 17.25 inches (43.8cm)
• Unit depth: 8.25 inches (20.9cm)
• Weight: approximately 8 lbs. (3.7kg)
• 19” Rack mountable or tabletop
• Finish: Black powder coat
