Installation and Operation Manual
ECN: 003155
Date: 06/4/2013
47
AC-SmartStart-7608-Series_IOM Rev 04
LAN Module & Communications
7.8.7 About
The About dialog displays identifying information about the agent software and provides
contact information and web/e-mail links.
7.9 SNMP and SMTP E-mail Alerts
The Network Agent software includes an SNMP agent, which provides read-only and
read-write access to a limited number of variables. These are defined in an SNMP MIB
and are shown in the following sections.
7.9.1 SNMP Variables
The OID’s shown in this table are relative to the enterprise OID 1.3.6.1.4.1.11923.
devcLineVoltageA read-only Line voltage for channel A, units are Volts x 10 1.1.1.1.1.1.0
devcLineVoltageB read-only Line voltage for channel B, units are Volts x 10 1.1.1.1.1.2.0
devcLoadCurrentA read-only Total load current for channel A, units are Amps x 100 1.1.1.1.1.3.0
devcLoadCurrentB read-only Total load current for channel B, units are Amps x 100 1.1.1.1.1.4.0
devcLineFrequencyA read-only Line frequency for channel A, units are Hz x 10 1.1.1.1.1.5.0
devcLineFrequencyB read-only Line frequency for channel B, units are Hz x 10 1.1.1.1.1.6.0
devcTemperature read-only Temp reading from optional external probe, units are degrees C x 10 1.1.1.1.1.7.0
devcSequence read-only Each char position contains a digit corresponding to an outlet number 1.1.1.1.1.8.0
devcSequenceDelay read-only Time delay between each outlet turning on or off in tenths of a second 1.1.1.1.1.9.0
devcPDUAddres read-only PDU address (0 to 255) 1.1.1.1.1.10.0
devcMasterSlave read-only Master/slave setting): 1 = standalone, 2 = master, 3 = slave 1.1.1.1.1.11.0
devcSoftwareVersion read-only Microprocessor software version 1.1.1.1.1.12.0
optdBaudRate read-only Baud rate: 1 = 4800, 2 = 9600, 3 = 19200, 4 = 38400 1.1.1.1.2.1.0
optdOutletsOffSimultaneous read-write Turn off all outlets simultaneously: 1 = execute 1.1.1.1.2.2.X
optdPowerOnCurrentLimitA read-only Power-on current limit for channel A, units are Amps x 10 1.1.1.1.2.3.0
optdPowerOnCurrentLimitB read-only Power-on current limit for channel A, units are Amps x 10 1.1.1.1.2.4.0
optdOutletsOnAll read-write Turns on outlets 1-8 in sequence: 1 = execute 1.1.1.1.2.5.X
OptdOutletsOnA read-write Turns on outlets 1-4 in sequence: 1 = execute 1.1.1.1.2.6.X
OptdOutletsOnB read-write Turns on outlets 5-8 in sequence: 1 = execute 1.1.1.1.2.7.X
OptdOutletsOffAll read-write Turns off outlets 1-8 in reverse sequence: 1 = execute 1.1.1.1.2.8.X
OptdOutletsOffA read-write Turns on outlets 1-4 in reverse sequence: 1 = execute 1.1.1.1.2.9.X
OptdOutletsOffB read-write Turns on outlets 5-8 in reverse sequence: 1 = execute 1.1.1.1.2.10.X
optdOutletDirect1 read-write On/off status of outlet 1: 0 = read status, 1 = off, 2 = on 1.1.1.1.2.11.X
optdOutletDirect2 read-write On/off status of outlet 2: 0 = read status, 1 = off, 2 = on 1.1.1.1.2.12.X
optdOutletDirect3 read-write On/off status of outlet 3: 0 = read status, 1 = off, 2 = on 1.1.1.1.2.13.X
optdOutletDirect4 read-write On/off status of outlet 4: 0 = read status, 1 = off, 2 = on 1.1.1.1.2.14.X
optdOutletDirect5 read-write On/off status of outlet 5: 0 = read status, 1 = off, 2 = on 1.1.1.1.2.15.X
optdOutletDirect6 read-write On/off status of outlet 6: 0 = read status, 1 = off, 2 = on 1.1.1.1.2.16.X
optdOutletDirect7 read-write On/off status of outlet 7: 0 = read status, 1 = off, 2 = on 1.1.1.1.2.17.X
optdOutletDirect8 read-write On/off status of outlet 8: 0 = read status, 1 = off, 2 = on 1.1.1.1.2.18.X
