Figure4.2
ReferenceforproperWheelViseinstallation.
4. Installation
Figure4.3
4Tie-DownEyeletsprovidedwiththisliftcanbe
placedinseverallocationsandmustbeusedto
secureloadsbeforeanyattemptismadetoliftthem.
4.5 VISE INSTALLATION AND EYE BOLTS
The Front Wheel Clamp mounts directly onto the front of either the Table Assembly or the
FrontExtension,dependingonwhichcongurationyouprefertosetyourliftupin(Thereare2
positionsontheFrontExtensionformounting-allowing3separatecongurations).Simplybolt
the Movable Clamp onto the left side of the Lift as you look at it from the rear using the provided
bolts. Next, mount the Fixed Clamp onto the right side of the lift.
The APlusLift MT1500 & MT1500X both come with an Adjustable Front Wheel Stop. To
install this piece, simply use the pin provider onto the front of the Table Assembly or Front
Extension, again depending on
whichconfigurationyouopttouseforyourlift.
  Always tie down the equipment on four corners using tie down
straps and tie down eyelets mounted on the lift’s table surface. do this every time before
operating lift! See Figure 4.3 for diagram of where Eyelets can be placed.
Please see the pictures below for proper installation of the Wheel Vise and information about
Tie-Down Eyelets.
