8. To lower the lift, raise the lift up off of the safety lock using the air foot pedal control, then, when the locking bar
is free, swing the bar back up to its mounting point underneath the lift. Now that the safety lock is disengaged,
you can lower the lift using the air foot pedal control to the ground.
9. Untie the equipment, you can now release the Front Wheel Vise, and push it off of the lift. ONCE AGAIN,
DO NOT DRIVE EQUIPMENT ONTO OR OFF OF THE LIFT!
5.3 Safety Lock Operation
AGAIN, THE PROPER OPERATION OF THE LIFT REQUIRES THAT ANY TIME YOU RAISE
EQUIPMENT, YOU MUST LOWER THE LIFT ONTO THE SAFETY LOCKS. As soon as you give
the Foot Peddle air to go up to the cylinder release the Safety Bar this is done by swinging
the
Lock Bar down into the locking ladder, by raising or lowering the lift using the foot
pedal controls until the Lock Bar rests on the next available lock. Note: The Foot Peddle
is not made to hold the load for any extended periods of time and will bleed down onto
the locks.
Tolowertheequipment,youmustrstraisetheliftoffofthelocksusingthefootpedalcontrol.
Then, when the locking bar is free, swing the bar back up to its mounting point underneath the
lift. Now that the safety lock is disengaged, you can lower the lift using the air foot pedal control
to the ground.
NEVER WORK UNDER OR NEAR THIS LIFT WITHOUT THE LOCKS
BEING ENGAGED. NEVER LEAVE RAISED EQUIPMENT ON THE LIFT
UNATTEN
DED. THE FOOT PEDDLE IS NOT DESIGNED TO BE A LOAD
-
HOLDING DEVICE. NOT USING THE SAFETY LOCKS WILL RESULT
IN A PREMATURE FAILURE OF THE CYLINDER AND/OR HOSES AND
CAN CAUSE SERIOUS PROPERTY DAMAGE OR PERSONAL INJURY!
FAILURE TO HEED THIS WARNING WILL RESULT IN IMMEDIATE
TER
MINATION OF YOUR WARRANTY.
