Apollo Valves DC4A User Manual

INSTALLATION, OPERATION, & MAINTENANCE MANUAL
www.apollovalves.com Customer Service (704) 841-6000
10
Inlet and Outlet Shut-O Valves
Item # Description
Std. or
LF
Qty.
Part Number
1/2” 3/4” 1” 1-1/4” 1-1/2” 2”
16
T2 Inlet NPT Ball Valve w/ “T”
Handle (Standard)
81 Mtl
1
77B-103-85 77B-104-83 77B-105-83
Not Available
LF 77BLF-103-85 77BLF-104-83 77BLF-105-83
T4 Inlet Union Ball Valve w/ “T”
Handle (Option)
81 Mtl 77B-303-85 77B-304-83 77B-305-83
Not Available
LF 77BLF-303-85 77BLF-304-83 77BLF-305-83
T2 Inlet NPT Ball Valve w/
Lever Handle (Standard)
81 Mtl
Not Available
77B-106-84 77B-107-84 77B-108-84
LF 77BLF-106-84 77BLF-107-84 77BLF-108-84
T4 Inlet Union Ball Valve with
Lever Handle (Option)
81 Mtl
Not Available
77B-306-84 77B-307-84 77B-308-84
LF 77BLF-306-84 77BLF-307-84 77BLF-308-84
T2 Inlet NPT Ball Valve with
Locking “T” Handle (Option)
81 Mtl
Not Available
77B-104-91 77B-105-91
Not Available
LF 77BLF-104-91 77BLF-105-91
T4 Inlet Union Ball Valve with
Locking “T” Handle (Option)
81 Mtl 77B-304-91 77B-305-91
Not Available
LF 77BLF-304-91 77BLF-305-91
T2 Inlet NPT Ball Valve with
Locking Lever Handle (Option)
81 Mtl
Not Available
77B-106-86 77B-107-86 77B-108-86
LF 77BLF-106-86 77BLF-107-86 77BLF-108-86
T4 Inlet Ball Union Valve with
Locking Lever Handle (Option)
81 Mtl
Not Available
77B-306-86 77B-307-86 77B-308-86
LF 77BLF-306-86 77BLF-307-86 77BLF-308-86
17
T2 Outlet NPT Ball Valve with “T”
Handle (Standard)
81 Mtl
1
77C-103-A4 77C-104-83 77C-105-83
Not Available
LF 77CLF-103-85 77CLF-104-83 77CLF-105-83
T4 Outlet Union Ball Valve with
“T” Handle (Option)
81 Mtl 77C-303-85 77C-304-83 77C-305-83
Not Available
LF 77CLF-303-85 77CLF-304-83 77C-305-83
T2 Outlet NPT Ball Valve with
Lever Handle (Standard)
81 Mtl
Not Available
77C-106-84 77C-107-84 77C-108-84
LF 77CLF-106-84 77CLF-107-84 77CLF-108-84
T4 Outlet Union Ball Valve with
Lever Handle (Option)
81 Mtl
Not Available
77C-306-84 77C-307-84 77C-308-84
LF 77CLF-306-84 77CLF-307-84 77CLF-308-84
T2 Outlet NPT Ball Valve with
Locking “T” Handle (Option)
81 Mtl
Not Available
77C-104-91 77C-105-91
Not Available
LF 77CLF-104-91 77CLF-105-91
T4 Outlet Union Ball Valve with
Locking “T” Handle (Option)
81 Mtl 77C-304-91 77C-305-91
Not Available
LF 77CLF-304-91 77CLF-305-91
T2 Outlet NPT Ball Valve with
Locking Lever Handle (Option)
81 Mtl
Not Available
77C-106-86 77C-107-86 77C-108-86
LF 77CLF-106-86 77CLF-107-86 77CLF-108-86
T4 Outlet Union Ball Valve with
Locking Lever Handle (Option)
81 Mtl
Not Available
77C-306-86 77C-307-86 77C-308-86
LF 77CLF-306-86 77CLF-307-86 77CLF-308-86
Replacement Handles for Ball Valve Shut-O Valves (T2 & T4 options)
“T” Handle
All
W-9732-00 W-9864-00 W-9734-00
Lever Handle Not Available W-9366-00
Locking “T” Not Available W-2394-00 Not Available
Locking Lever Not Available W-9686-00
Stainless steel handles are standard on all Apollo® backow devices.
