Apollo Valves DC4A - Parts and Components; DC4 A and DCLF4 A Parts List; Check Module Sub-Assembly Parts

9
BFMM DC4A SBF
Customer Service (704) 841-6000 www.apollovalves.com
DC4A and DCLF4A Parts List
Item # Description
Std. or
LF
Qty.
Part Number
1/2” 3/4” 1” 1-1/4” 1-1/2” 2”
1 Body All 1 Consult Factory
2 Label Plate All 1 Consult Factory
3 Label Plate Tacks All 2 I-2614-00
4
Test Cock M x F (81 metal) Std
4
78-290-01 (Optional) 78-291-01 (Standard)
Test Cock M x F (Lead Free) LF 78LF-290-01 (Optional) 78LF-291-01 (Standard)
4a
Test Cock SAE (81 metal) Std 78-292-01 (Standard) 78-293-01 (Optional)
Test Cock SAE (Lead Free) LF 78LF-292-01 (Standard) 78LF-293-01 (Optional)
5
Cap (81 metal) Std
2
F-3846-05 F-3822-05 F-3848-05 F-3850-05 F-3854-05
Cap (Lead Free) LF F-3847-05 F-3823-05 F-3849-05 F-3851-05 F-3855-05
6 Cap O-Ring All 2 D-4881-00 D-4812-00 D-4884-00 D-4885-00 D-4888-00
7 Check Module O-Ring All 2 D-4880-00 D-4744-00 D-4882-00 D-4884-00 D-4885-00
8 Check S-Assy (see below) All 2 W-9075-05 W-9003-05 W-9074-05 W-9159-05 W-9204-05
Individual parts are only available for bulk sales. Please refer to the appropriate repair kits on pages 11.
Check Module Sub-Assembly Parts LIst
Item # Description
Std. or
LF
Qty.
Part Number
1/2” 3/4” 1” 1-1/4” 1-1/2” 2”
9 Check Seat All 1 L-7815-00 L-7727-00 L-7813-00 L-7979-00 L-7983-00
10 Screw All 1 B-3279-00 B-1750-00
11 Disc Retaining Washer All 1 E-2372-00 E-2841-00 E-2933-00 E-2860-00 E-2876-00
12 Seat Disc All 1 D-4771-00 D-4743-00 D-4770-00 D-4853-00 D-4873-00
13 Poppet All 1 K-4491-00 K-4471-00 K-4483-00 K-4511-00 K-4512-00
14 Spring All 1 A-2505-00 A-2503-00 A-2510-00 A-2511-00 A-2512-00
15 Spring Retainer All 1 L-7814-00 L-7726-00 L-7812-00 L-7980-00 L-7984-00
Individual parts are only available for bulk sales. Please refer to the appropriate repair kits on pages 11.
