Apollo HD Series Start Guide

18
to view current IP information. Besides, when PPPoE is operating, you can not modify
IP/Subnet mask /Gateway.
 TCP port: Default value is 37777.
 UDP port: Default value is 37778.
 HTTP port: Default value is 80.
 Max connection: system support maximal 10 users. 0 means there is no connection limit.
 Transfer mode: Here you can select the priority between fluency/video qualities.
 Network download: System can process the downloaded data first if you enable this function.
 Advanced setting: Please refer to the user’s manual included in the resource CD for detail
information.
After completing all the setups please click save button, system goes back to the previous menu.
Figure 2-12
2.5 Pan/Tilt/Zoom
Please note:
 Slight difference may be found in the user’s interface, due to various protocols.
 Please make sure the speed domes A/B cables are properly connected to the A/B ports of
DVR.
 You have properly set PTZ information.
 Please switch camera monitor channel to current window.
2.5.1 PTZ setup
The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 2-13.
 Protocol: Select corresponding PTZ protocol such as PELCOD.
 Address: Input corresponding PTZ address.
 Baud rate: Select baud rate.
 Data bit: Select data bit. Default value is 8.
 Stop bit: select stop bit. Default value is 1.
 Parity: there are three choices: none/odd/even. Default value is none.

Apollo HD Series Specifications

General

Category	DVR
Video Compression	H.264
Hard Drive Capacity	Up to 6TB
Remote Viewing	Yes
Operating System	Embedded Linux
Video Input	4/8/16 channels
Recording Resolution	1080p/720p
Mobile Support	iOS, Android
