Please refer to Figure 1-5 for connection sample.

Figure 1-5

1.8 Alarm Input and Output Connection

There are two alarm input types for you to select: normal open (NO) and normal close (NC).

1.8.1 Alarm Input and Output Details

Figure 1-6

You can refer to the following sheet and Figure 1-6 for alarm input and output information.

Parameter

Grounding Alarm

Ground line

Alarm Input 1, 2, …, 8. It becomes valid in low voltage.

AB Connection

port
