Application Systems ADX-32 - Digital 24;8 Multicore (Sync over ADAT)

9.2. Digital 24/8 multicore (sync over ADAT)
11
ADAT Lightpipe
ADAT Lightpipe (used only for wordclock sync)
Cat.5 cable
Analog cable
ADC / DAC (Wordclock slave)
ADC / DAC (Wordclock slave)
Mixer
(Wordclock Master)
Mixer
(Wordclock Master)
ADX-32
ADX-32
1
In Out
2
In Out
3
In Out
4
In Out
A Cat.5 B
ADX-32
ADX-32
In Out
1
In Out
2
In Out
3
In Out
4
A Cat.5 B
ADC / DAC (Wordclock slave)
ADC / DAC (Wordclock slave)
(unused)
ADC / DAC (Wordclock slave)
ADC / DAC (Wordclock slave)
(unused)
